Copper Alloy Tube JIS H 3330 C1220T Copper Nickel Seamless Condenser Tubes

Thông tin chi tiết sản phẩm:

Place of Origin:	CHINA
Hàng hiệu:	YUHONG
Chứng nhận:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	C1220T,C1220TS

Thanh toán:

Minimum Order Quantity:	100KGS
Packaging Details:	PLYWOOD CASE,BUNDLE,PALLET
Delivery Time:	7DAYS
Payment Terms:	L/C, T/T

Tiếp xúc

Tất cả sản phẩm

Dàn ống thép không gỉ (285)

Dàn ống thép không gỉ (273)

ống thép không gỉ kép (127)

ống thép không gỉ kép (28)

Thủy ống kim (98)

ống vây (608)

Bộ trao đổi nhiệt (15)

Ống trao đổi nhiệt (424)

Bộ ống trao đổi nhiệt (37)

Tấm trao đổi nhiệt (115)

Bộ đệm trao đổi nhiệt (36)

máy làm mát không khí (7)

Bình chịu áp lực (4)

ống hàn thép không gỉ (57)

Ống hàn thép không gỉ (112)

Niken hợp kim ống (259)

ống hợp kim niken (75)

Ống hợp kim đồng (219)

ống thép hợp kim (177)

ống titan (9)

Ống ủ sáng (153)

Ống nồi hơi (138)

lắp thép (791)

mặt bích thép (577)

Người khác (386)

Các bộ phận lớp phủ (5)

Chi tiết sản phẩm

MATERIAL:	C1220T,C1220TS	STANDARD:	JIS H 3330
OD:	12.7MM,19.05MM,25.4MM....	WT:	0.89MM,1.2MM,1.5MM...
STATUS:	O,OL,1/2H,H	TEST:	ET, HT, Flattening Test,Expansion Test, Mercurous Nitrate Test; Ammonia Vapor Test; Chemical Analysis; Microscopical Examination,Tension Testing.
Làm nổi bật:	C1220T Seamless Condenser Tubes , JIS Copper Alloy Tube , Copper Nickel Seamless Condenser Tubes

Copper Alloy Tube JIS H 3330 C1220T Copper Nickel Seamless Condenser Tubes

What is JIS H 3330 C1220T tube?

JIS H 3330 C1220T refers to a phosphorus-deoxidized copper tube standard specified by the Japanese Industrial Standards (JIS).

Key Features of JIS H 3330 C1220T Tube:

1. Material:

- C1220 (Phosphorus-Deoxidized Copper, DHP Copper)

- Contains a small amount of phosphorus (0.015–0.040%) for deoxidation, improving weldability and resistance to embrittlement.

- High thermal and electrical conductivity (though slightly lower than pure copper due to phosphorus content).

- Excellent corrosion resistance, especially in water and steam applications.

Grade	Chemical Composition%		Tensile Strength
	Cu	P	N/mm2
C1220T	99.9	0.015	315
		0.040

2. Standard:

- JIS H 3330 covers seamless copper and copper alloy tubes for general piping.

3. Applications:

- Plumbing & HVAC systems (water supply, heating, refrigeration).

- Gas distribution, medical gas systems, and industrial piping.

- Often used where brazing or welding** is required.

4. Comparable Standards:

- ASTM B68 (C12200) – U.S. equivalent.

- EN 1057 (CW024A) – European equivalent.

What is the advantage of JIS H 3330 C1220T tube?

High Conductivity: C1220 copper tubes offer excellent electrical conductivity, making them ideal for electrical and electronic applications.
Thermal Conductivity: These tubes have superior thermal conductivity, facilitating efficient heat transfer in heating, cooling, and refrigeration systems.
Corrosion Resistance: C1220 copper exhibits excellent corrosion resistance, ensuring durability and longevity in various environments.
Ease of Fabrication: C1220 copper is easily formable and weldable, allowing for seamless tube production and customization to meet specific requirements.

Dimensional Range

Outer Diameter - 4.00 to 22.00 mm
Wall Thickness - Between 0.15mm and 1.50 mm
Length upto 6 mtrs
End Applications

Heat Exchangers, Oil Coolers, Radiators, High Capacity Power Plants, Ship Building & Ship Repairs, Condensers, Offshore Oil rigs, Distiller Tubes, Evaporators, Ferrules etc.

Copper Alloy Tube JIS H 3330 C1220T Copper Nickel Seamless Condenser Tubes 0
