| Nguồn gốc: | Trung Quốc |
| Hàng hiệu: | YUHONG |
| Chứng nhận: | ISO13485:2016 |
| Số mô hình: | SUS304 |
| Số lượng đặt hàng tối thiểu: | 50 kg |
|---|---|
| Giá bán: | Có thể đàm phán |
| chi tiết đóng gói: | Hộp carton, hộp nhựa, vỏ gỗ dán |
| Thời gian giao hàng: | 15 - 45 ngày làm việc |
| Điều khoản thanh toán: | T/t, l/c |
| Khả năng cung cấp: | 13 tỷ mảnh mỗi năm |
| Tên sản phẩm: | Bụi mạch máu vỏ thép không gỉ y tế | Tiêu chuẩn ống mao quản: | ISO9626: 2016 (Y khoa), ASTM A269 (Công nghiệp) |
|---|---|---|---|
| Vật liệu ống mao dẫn: | SUS304, AISI304, 1.4301, X5CRNI18-9, 06CR19NI10 | Đường kính ngoài ống mao dẫn: | 0,15mm-3,4mm hoặc theo yêu cầu |
| Dung sai đường kính ngoài: | Thông thường trong phạm vi ± 0,005mm đến ± 0,013mm | Dung sai độ dày của tường: | Thông thường trong phạm vi ± 0,005mm đến ± 0,010mm |
| Chiều dài ống mao dẫn: | 2 mét hoặc cắt vào chiều dài ống kim | Bề mặt ống mao dẫn hoàn thiện: | Đánh bóng |
Medical Stainless Steel 304 Precision Capillary Tube For Hypodermic Needles ISO9626 1.4301
Medical grade stainless steel micro capillary tubes are small-diameter hollow high-precision tubes made from stainless steel 304 grade, which are usually used in medical devices and equipments, like injection needle tubes, infusion needle tubes, IV cannulas, catheters, etc.. These capillary tubes are known for their high precision, good durability, good formability, strength, and excellent resistance to corrosion. These stainless steel capillary tubes are not the final needle tubes but they are the essential raw material that medical needle tube manufacturers use. They are cold drawn to highly precise dimensions and undergo rigorous processing to ensure they meet the stringent demands of piercing human skin and delivering or extracting fluids safely.
Our company has manufactured stainless steel capillary tubes for more than 30 years, not only used for medical devices, but also for industrial applications. For medical use, these capillary tubes are usually cut into fixed needle tube length and ground with special bevel needle tips. Our medical capillary tubes are produced according to ISO9626 standard, which have tight dimensional tolerance and good surface. We can also provided based on clients’ detailed tolerance requirements.
Regular Sizes For Hypodermic Usage (Diameter, Wall Thickness, Length):
| Needle Gauge (G) | Outer Diameter (OD) | Common Wall Thickness (WT) | Inner Diameter (ID) |
| 18G | 1.27 mm | 0.20 mm | 0.87 mm |
| 21G | 0.82 mm | 0.13 mm | 0.56 mm |
| 23G | 0.64 mm | 0.11 mm | 0.42 mm |
| 25G | 0.51 mm | 0.08 mm | 0.35 mm |
| 27G | 0.41 mm | 0.07 mm | 0.27 mm |
| 30G | 0.31 mm | 0.06 mm | 0.19 mm |
Length: Capillary tubes are generally supplied in straight lengths, commonly ranging from 1 to 2 meters, which are then cut to the required needle length(18mm, 25mm, 30mm, 32mm, 45mm, etc.).
Key Features Of Medical Capilalry Tubes:
Different Applications Of Stainless Steel Capillary Tubes:
The stainless steel capillary tubes are ideal for numerous medical and non-medical applications:
1. Medical Applications:
2. Industrial & Non-Medical Applications:
